Name: JZP-4.2-SC-SC1 Series Rubber Shock Absorber with 4.2Kg Max Static Load 7Hz-15Hz Natural Frequency and ISO 9001:2015 Certification
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-4.2-SC-SC1
Availability: InStock

Zu Hause > produits > Gummistoßdämpfer >

JZP-4.2-SC-SC1 Series Rubber Shock Absorber with 4.2Kg Max Static Load 7Hz-15Hz Natural Frequency and ISO 9001:2015 Certification

4.2Kg Max Static Load Rubber Shock Absorber

7Hz-15Hz Natural Frequency Vibration Isolator

ISO 9001:2015 Certified Friction Damping Isolator

Herkunftsort:

CHINA

Markenname:

Hoan

Modellnummer:

JZP-4.2-SC-SC1

Kontakt mit uns

Bitte um ein Angebot

JZP-4.2-SC-SC1 Series Rubber Shock Absorber with 4.2Kg Max Static Load 7Hz-15Hz Natural Frequency and ISO 9001:2015 Certification

Einzelheiten zum Produkt

Max statische Last:

4,2 kg

Kompressionsverhältnis:

1: 2

Breite:

50 mm

Maximale Ablenkung:

1 Zoll

Inneres tiefes:

10 mm

Druckbereich:

Hoch

Produktschlüsselwörter:

mit einer Leistung von mehr als 1000 W

Eigenfrequenz:

7Hz-15Hz

Temperaturwiderstand:

Kann extremen Temperaturen standhalten

Eigenschaften:

Elastisches gutes, Verschleißfestigkeit

Zertifizierungen:

ISO 9001: 2015

Material:

Gummi

Flexibilität:

Flexibel

Leistung:

Stoßfest

Garantie:

1 Jahr

Hervorheben:

4.2Kg Max Static Load Rubber Shock Absorber

7Hz-15Hz Natural Frequency Vibration Isolator

ISO 9001:2015 Certified Friction Damping Isolator

Zahlungs- und Versandbedingungen

Min Bestellmenge

Zahlungsbedingungen

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Verwandte Produkte

JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing

Beste Preis erhalten

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

Beste Preis erhalten

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

Beste Preis erhalten

JZP-7.5-SC-SC1 Friction Damping Vibration Isolator with Up to 90% Vibration Isolation M5 Mounting Thread Size and 50N/mm Axial Stiffness

Beste Preis erhalten

Kontakt mit uns

86-29-88292913

Kontaktieren Sie uns jetzt

Beschreibung des Produkts

JZP-4.2-SC-SC1 Series The Ultimate Solution for Laboratory Vibration Isolation Rubber Shock Absorber

Beyond Tradition: Why the JZP-sc-sc1 Friction Damping Vibration Isolator Is a Better Choice for Laboratories

The JZP-sc-sc1 series friction damping vibration isolators from Xi'an Hoan Microwave offer laboratory users an alternative that matches traditional solutions in performance while providing greater cost-effectiveness and convenience.

Key Advantages

Solid-phase vibration isolation concept requires no air supply or power source
Ready to use immediately after installation with nearly maintenance-free operation
Compact design for easy integration into standard laboratory workbenches
Effective suppression of mid-to-low frequency vibrations (building vibrations, personnel movement, etc.)
Reduces instrument stabilization waiting time, improving experimental efficiency
Damping performance remains stable over time and temperature variations

Dimension Parameters

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	b (mm)
JZP-SC-SC1	60	36	24.5	50	60	M5	∅5.5	5	28

Technical Parameters

Model	Nominal Load (KG)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Limited Period
JMZ-3.2-SC-SC1	3.2	≤0.3	-45～+65	41.5±5	100g 12 times	8
JMZ-4.2-SC-SC1	4.2
JMZ-5.2-SC-SC1	5.2
JMZ-6.0-SC-SC1	6.0
JMZ-7.0-SC-SC1	7.0
JZP-7.5-SC-SC1	7.5
JZP-9.0-SC-SC1	9.0
JZP-10.5-SC-SC1	10.5
JZP-13.5-SC-SC1	13.5
JZP-15-SC-SC1	15
