JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

10Hz to 100Hz Frequency Range Rubber Shock Absorber

-55 to +120 Working Temperature Vibration Isolator

Horizontal/Vertical Installation Passive Vibration Isolator

Herkunftsort:

CHINA

Markenname:

Hoan

Modellnummer:

JZP-10.5-SC-SC1

Kontakt mit uns
Bitte um ein Angebot
JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation
Einzelheiten zum Produkt
Durchmesser:
0,25-2 Zoll
Besonderheit:
Vibrationsisolation
Zubehör:
Netto
Breite:
50 mm
Leistung:
Stoßfest
Produktzertifizierung:
ISO 9001
Installationstyp:
Horizontal/vertikal
Montageorientierung:
Vertikal
Schwingungsfrequenzbereich:
10 Hz bis 100 Hz
Arbeitstemperatur:
: -55 ~ +120
OEM:
Ja
Vibrationsisolationstyp:
Passiv
Hervorheben:

10Hz to 100Hz Frequency Range Rubber Shock Absorber

,

-55 to +120 Working Temperature Vibration Isolator

,

Horizontal/Vertical Installation Passive Vibration Isolator

Zahlungs- und Versandbedingungen
Min Bestellmenge
4
Zahlungsbedingungen
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Verwandte Produkte
Ein guter Preis. JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing Online

JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing

Beste Preis erhalten
Ein guter Preis. JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation Online

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

Beste Preis erhalten
Ein guter Preis. JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery Online

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

Beste Preis erhalten
Ein guter Preis. JZP-7.5-SC-SC1 Friction Damping Vibration Isolator with Up to 90% Vibration Isolation M5 Mounting Thread Size and 50N/mm Axial Stiffness Online

JZP-7.5-SC-SC1 Friction Damping Vibration Isolator with Up to 90% Vibration Isolation M5 Mounting Thread Size and 50N/mm Axial Stiffness

Beste Preis erhalten
Kontakt mit uns
86-29-88292913
Kontaktieren Sie uns jetzt
Beschreibung des Produkts
JZP-10.5-SC-SC1 Redefining Precision Equipment Stability with Xi'an Hoan Microwave's Rubber Shock Absorber
JZP-SC-SC1 Series
At the frontier of nanoscale science exploration, laboratory environment stability is essential for experimental success. The JZP-sc-sc1 series vibration isolators from Xi'an Hoan Microwave provide extreme stability for high-sensitivity instruments.
Key Advantages
  • Passive mechanical design ensures absolute reliability with zero energy consumption
  • No external power required, eliminating risks from power fluctuations
  • Superior attenuation of structural low-frequency vibrations (1-100Hz range)
  • Eliminates creep and aging issues of traditional vibration isolation materials
  • Maintains long-term stable stiffness and damping performance
Ideal Applications
Optical platforms, atomic force microscopes (AFMs), gene sequencers, and other high-precision instruments requiring vibration-free environments.
Dimension Parameters
JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation 0
Model D (mm) H±1 (mm) h (mm) A±0.2 (mm) B (mm) d d2 R b (mm)
JZP-SC-SC1 60 36 24.5 50 60 M5 ∅5.5 5 28
Technical Parameters
Model Nominal Load (KG) Static Displacement (mm) Working Temperature (℃) Resonance Frequency (Hz) Impact Test Limited Period
JMZ-3.2-SC-SC1 3.2 ≤0.3 -45～+65 41.5±5 100g 12 times 8
JMZ-4.2-SC-SC1 4.2 Same as above
JMZ-5.2-SC-SC1 5.2 Same as above
JMZ-6.0-SC-SC1 6.0 Same as above
JMZ-7.0-SC-SC1 7.0 Same as above
JZP-7.5-SC-SC1 7.5 Same as above
JZP-9.0-SC-SC1 9.0 Same as above
JZP-10.5-SC-SC1 10.5 Same as above
JZP-13.5-SC-SC1 13.5 Same as above
JZP-15-SC-SC1 15 Same as above
